Lufthansa API Integration Guide

• Understand what the Lufthansa Open API can and cannot do for schedules and trip planning.
• Set up developer access and generate a working OAuth2 access token.
• Successfully call the Flight Schedules endpoint and read its response.
• Use schedule data as a building block for trip planning logic.
• Establish a clear, low-effort path to sync or look up this data inside Odoo.

• Flight Schedules API covers seven Lufthansa Group airlines: LH, EN, LX, OS, WK, SN, 4Y.
• Access uses OAuth2 client_credentials - you need a Client ID and Client Secret from the developer portal.
• Access tokens expire (commonly every 6 hours) and must be refreshed, not requested per call.
• A known quirk: the API returns "bearer" lowercase but expects "Bearer" uppercase in the request header.
• The API returns schedules only - no pricing, seat availability, or booking. Those need a separate Partner Plan agreement.
• Flight times in responses are minutes-from-midnight, not HH:MM - conversion is required on your end.
• Odoo integration is done as a custom module; there is no ready-made connector.
• Two integration patterns fit most use cases: a scheduled daily sync, or an on-demand lookup triggered from a form/button.

The Lufthansa Open API is a REST API published by Lufthansa Group. For flight schedules and trip planning, the relevant service is the Flight Schedules API.

It returns schedule data for the following Lufthansa Group airlines:

LH (Lufthansa), EN (Air Dolomiti), LX (Swiss), OS (Austrian), WK (Edelweiss), SN (Brussels Airlines), 4Y (Eurowings Discover)

You can search schedules by:

• Airline
• Flight number
• Start and end date
• Days of operation
• Origin and destination
• Aircraft type

Passenger flight schedule access is open on the Public Plan. Full/bulk schedule listing and cargo schedules are restricted and need a Partner Plan (contact Lufthansa directly).

Step 1 - Create a developer account at https://developer.lufthansa.com and register an application. You will receive a Client ID and Client Secret.

Step 2 - Subscribe your application to the "Flight Schedules" API product (Public Plan is enough to start).

Step 3 - Request an OAuth2 access token before calling any endpoint.

Token endpoint

POST https://api.lufthansa.com/v1/oauth/token
Content-Type: application/x-www-form-urlencoded

Parameters sent as form data:

• client_id = your client key
• client_secret = your client secret
• grant_type = client_credentials

Example request

curl "https://api.lufthansa.com/v1/oauth/token" -X POST -d "client_id=YOUR_CLIENT_ID" -d "client_secret=YOUR_CLIENT_SECRET" -d "grant_type=client_credentials"

Example response

{ "access_token": "d8bmzggu72dy69tzkffe6vaa", "token_type": "bearer", "expires_in": 21600 }

Notes

• The token is valid for a limited time (expires_in is in seconds, typically 6 hours).
• When sending the token on later requests, the header must use "Bearer" with a capital B, even though the response says "bearer" lowercase. This is a known quirk in Lufthansa's API.
• Store the token and refresh it before it expires. Do not request a new token on every single call.

Once you have a valid token, call:

GET https://api.lufthansa.com/v1/flight-schedules/flightschedules/passenger

Send the token as a header:

Authorization: Bearer YOUR_ACCESS_TOKEN

Example request with query parameters

GET /flight-schedules/flightschedules/passenger?airlines=LH&flightNumberRanges=400-405&startDate=05DEC19&endDate=10DEC19&daysOfOperation=1234567&timeMode=UTC

Common query parameters

• airlines - airline code, e.g. LH
• flightNumberRanges - single number or range, e.g. 400-405
• startDate / endDate - format DDMMMYY, e.g. 05DEC19
• daysOfOperation - digits 1–7 representing Mon–Sun
• origin / destination - IATA airport codes
• timeMode - UTC or LT (local time)

The response is a JSON array. Each entry contains:

• airline and flightNumber
• periodOfOperationUTC / periodOfOperationLT - validity dates and days of operation
• legs - one entry per flight leg, with origin, destination, aircraft type, and departure/arrival times
• dataElements - extra IATA SSIM-standard fields (codeshares, meal service, etc.)

Times in the response are given as minutes from midnight, not as HH:MM strings. You will need to convert them in your own code (e.g. 590 minutes = 09:50).

The Flight Schedules API only returns schedules - it does not do fare pricing, seat availability, or booking. A typical "trip planning" flow looks like this:

Step 1 - Use the Reference Data endpoints (Airports, Cities, Countries, Nearest Airport) to resolve city names to IATA airport codes.

Step 2 - Call Flight Schedules with origin, destination, and travel dates to get candidate flights.

Step 3 - If you need live delays/gate info instead of the base timetable, use the separate Flight Status API instead of Flight Schedules.

Step 4 - Assemble multi-leg trips yourself in your application logic by matching arrival airports to onward departure airports, since the API does not build itineraries for you.

Step 5 - If you need actual fares, you need the Partner API (Offers section) which requires a commercial partner agreement - it is not open to Public Plan developers.

Odoo does not have a native Lufthansa connector, so integration is done as a custom module. There are two common approaches.

• Build a small Odoo module with a scheduled action (ir.cron).
• The cron job calls the OAuth token endpoint, then the Flight Schedules endpoint, on a timer (e.g. once a day).
• Store results in a custom Odoo model, for example x_flight_schedule, with fields for airline, flight number, origin, destination, departure time, arrival time, and days of operation.
• Use Odoo's requests library (already available in Odoo's Python environment) to make the HTTP calls.
• Cache the access token in a system parameter (ir.config_parameter) along with its expiry time, so you are not requesting a new token on every cron run.

• Add a button or wizard on a relevant Odoo view (e.g. a Travel Request or Booking form in HR/Project modules).
• When clicked, the module calls the Flight Schedules API live with the dates and route entered by the user, and displays matching flights in a list for the user to pick from.
• This suits ad-hoc trip planning better than a nightly sync.
