By: Ruksana P

How to Load PoS Session Data to PoS Order in Odoo 16

Technical Odoo 16

In  Odoo 16, we can extend the functionality by adding new fields and modifying the workflows to meet the specific business requirements in POS. Adding custom models and fields was discussed earlier. In this blog, we are loading POS session (front-end) data into POS order (backend).  As an example, we want to add customer suggestions to POS orders from the session.

Step 1: Add a new field to the POS orde

Add a new custom field to the POS order, there is no need to load this field to the POS session since this field value is set from the front end.

# -*- coding: utf-8 -*-
from odoo import fields, models

class PosOrder(models.Model):
   _inherit = 'pos.order'

   suggestion = fields.Char(string='Customer Suggestion', readonly=True,
                            help='Customer suggestion can see here')

In this code, we can add the field ‘suggestion’ to the POS order. Update the POS order view to include the newly added customer_suggestion field in the extra page of the POS order.

<?xml version="1.0" encoding="UTF-8" ?>
<!--To add new field suggestion to pos order-->
   <record id="view_pos_pos_form" model="ir.ui.view">
       <field name="name">pos.order.pos.order.type</field>
       <field name="model">pos.order</field>
       <field name="inherit_id" ref="point_of_sale.view_pos_pos_form"/>
       <field name="arch" type="xml">
           <xpath expr="//page[@name='extra']" position="inside">
               <group string="Customer Feedback">
                   <field name="suggestion"/>

Step 2: Add a customer suggestion button to the POS

To enhance customer engagement and satisfaction, we have seamlessly integrated a customer suggestion button into the payment screen of our POS module. In order to add a customer suggestion button on the payment screen, inherit the ‘PaymentScreen’ template and add a new button after the tip button.
<?xml version="1.0" encoding="UTF-8"?>
<templates id="template" xml:space="preserve">
   <t t-inherit="point_of_sale.PaymentScreen" t-inherit-mode="extension">
       <!--  Shows the customer suggestion to the payment screen -->
       <xpath expr="//div[hasclass('payment-controls')]" position="inside">
              <div id="suggestion" class="button"
                  <i class="fa fa-file-text-o"/>
                  Customer Suggestion
Now we can see the customer suggestion button in ‘PaymentScreen’. In order to add the functionality for the customer suggestion button, we want to add a click function for that button.

How to Load PoS Session Data to PoS Order in Odoo 16-cybrosys

Step 3: Add a new component suggestion button to the POS

The Odoo16 allows customization of the POS module to meet specific business requirements.  We can add custom fields, modify workflows, and extend functionality through Odoo’s flexible app ecosystem.  In this example, we can add the click function of user suggestions.

/** @odoo-module **/
import Registries from 'point_of_sale.Registries';
import  PaymentScreen from 'point_of_sale.PaymentScreen';

const ExtraChargeButton = (PaymentScreen) =>
   class extends PaymentScreen {
       setup() {
       async customer_suggestion(){
       const { confirmed, payload } = await this.showPopup('EditListPopup', {
       title: this.env._t('Customer Suggestion'),
       body: this.env._t('This click is successfully done.'),
       if (confirmed) {
Registries.Component.extend(PaymentScreen, ExtraChargeButton);
return ExtraChargeButton;
By clicking the customer suggestion, a text popup will appear, and the user can enter the suggestion here. By clicking OK, it will be added to the POS order.

How to Load PoS Session Data to PoS Order in Odoo 16-cybrosys

Step 3: Load customer suggestions from the POS session to the POS order

For this, we have to store the customer suggestion in the browser and send it to the backend when the order is confirmed. To do this, we can add a js file to our custom module. In order to avoid losing of data when refreshing the page, we can add the init_from_JSON (json) function, and we can override the export_as_JSON() function to send the customer suggestion to the server.

/** @odoo-module **/

import models from 'point_of_sale.models';
import {Order} from 'point_of_sale.models';
import  Registries from "point_of_sale.Registries";
const Suggestion = (Order) => class Suggestion extends Order {
     constructor() {
     this.suggestion = this.suggestion || null;
     this.suggestion = suggestion
     //send order data to send to the server
     export_as_JSON() {
     const json = super.export_as_JSON(...arguments)
     json.suggestion = this.suggestion ;
     return json;
     init_from_JSON(json) {
      this.suggestion = json.suggestion;
     Registries.Model.extend(Order, Suggestion);
And finally, override the method in the POS order ‘_order_fields()’ to store the front-end customer suggestion to the POS order. It will add a new key-value pair to the dictionary for the create method.
def _order_fields(self, ui_order):
   """ Prepare dictionary for create method """
   result = super()._order_fields(ui_order)
   result['suggestion'] = ui_order.get('suggestion')
   return result

Now we can go to the POS order and see the customer suggestion in POS order.

How to Load PoS Session Data to PoS Order in Odoo 16-cybrosys

By extending the method ‘export_as_JSON’, we can send any custom field value to the server, and that can be loaded into the backend POS order by using the ‘_order_fields()’ method.
