Widgets List in Odoo 14

We have different types of widgets for different purposes helping us with the simplification of the operations. Widgets are used to make the code easy and user-friendly which will be helpful in the coding as well as programming aspects of the software. In Odoo 14 development we can make use of the different widgets which can be used in the operations of the programming certain specific aspects of the operation. These are tools of simplification that will pave the way for the ease of programming operations.

In this blog, we are going to discuss different widgets that can be applied in the Odoo field.

All the Widget tools that can be used in Odoo are defined along with the index involved with it. In total, we have covered 30 types of widget tools that are used in Odoo throughout this blog. Moreover, the field type of operation of the respective widget along with the illustrator screenshot of the respective widget of operation in the Odoo platform has been defined for a clearer perspective of the operation.

Let's now move on to understand each of the widgets one by one.

1. badge

Field Type: Many2one, Selection

<field name="state_id" widget="badge" />









2. remaining_days

Field Type: Datetime

<field name="expiration_date" widget="remaining_days"/>









3. color_picker

Field Type: Integer

<field name="color" widget="color_picker"/>






4. char_emojis / text_emojis

Field Type: Char, Text




 <field name="subject" string="Subject" widget="char_emojis"/>









5. forecast_widget

Field Type: Float




<field name="forecast_availability" string="Reserved" widget="forecast_widget"/>









6. many2one_avatar_employee

Field Type: Many2one




<field name="employee_id" widget="many2one_avatar_employee"/>









7. many2one_avatar_employee

Field Type: Many2one




<field name="user_id" widget="many2one_avatar_user"/>









8. priority

Field Type: Selection




priority = fields.Selection([('0', 'Normal'),('1', 'Good'),('2', 'Very Good'),('3', 'Excellent')], "Appreciation", default='0')
<field name="priority" widget="priority"/>









9. product_discount

Field Type: Float




<field name="discount" string="Disc.%"  widget="product_discount"/>









10. list_activity

Field Type: One2many




<field name="activity_ids"  widget="list_activity"/>









11. kanban_activity

Field Type: One2many




<field name="activity_ids" widget="kanban_activity"/>









12. account_resequence_widget

Field Type: Text




<field name="preview_moves" widget="account_resequence_widget"/>









13. stock_rescheduling_popover

Field Type: Char




 <field string=" " name="json_popover" widget="stock_rescheduling_popover"/>









14. mrp_should_consume

Field Type: Float




 <field name="product_uom_qty" widget="mrp_should_consume" string="To Consume" width="1"/>









15. mrp_workorder_popover

Field Type: Char




<field name="json_popover" widget="mrp_workorder_popover" string=" " width="0.1" attrs="{'invisible': [('show_json_popover', '=', False)]}"/>









16. popover_widget

Field Type: Char




<field name="json_lead_days_popover" optional="show" nolabel="1" string="Forecast Description" width="10px" widget="popover_widget"/>









17. kanban_vat_activity

Field Type: Boolean




<field name="json_activity_data" widget="kanban_vat_activity"/>









18. many2one_barcode

Field Type: Many2one




<field name="product_id"context="{'partner_id': parent.partner_id}" widget="many2one_barcode"domain="[('purchase_ok', '=', True), '|', ('company_id', '=', False), ('company_id', '=', parent.company_id)]"/>









19. text

Field Type: Text, Char




<field name="description" widget="text"/>









20. many2manyattendee

Field Type: Many2many




<field name="partner_ids"  widget="many2manyattendee" placeholder="Select attendees..." context="{'force_email':True}" class="oe_inline"/>









21. many2many_tags_avatar

Field Type: Many2many




<field name="partner_ids"  widget="many2many_tags_avatar" placeholder="Select attendees..." context="{'force_email':True}" class="oe_inline"/>









22. website_urls

Field Type: Char




<field name="regex_url" widget="website_urls" placeholder="e.g. /page"/>









23. domain
24. Fied Type: Char

<field name="filter_domain" widget="domain"/>









25. boolean_favorite

Field Type: Boolean




<field name="is_favorite" widget="boolean_favorite" nolabel="1"/>









26. account_hierarchy_selection

Field Type: Many2one




<field name="user_type_id" widget="account_hierarchy_selection"/>









27. percentage

Field Type: Float




<field name="percentage"  widget="percentage" />









28. task_with_hours

Field Type: Many2one




<field name="task_id" widget="task_with_hours" domain="[('project_id', '=', project_id)]"/>









29. timesheet_uom_no_toggle

Float Type: Float




<field name="planned_hours" widget="timesheet_uom_no_toggle" sum="Initially Planned Hours" optional="hide"/>









30. CopyClipboardChar

Float Type: Char




<field name="link" readonly="1" widget="CopyClipboardChar"/>









31. boolean_toggle

Float Type: Boolean




<field name="active" widget="boolean_toggle"/>









32. sms_widget

Float Type: Char, Text




<field name="body" widget="sms_widget"/>









33. selection_badge

Float Type: Selection




<field name="progression" widget="selection_badge"/>









34. timesheet_uom_timer

Float Type: Float




<field name="unit_amount" string="Time Spent" widget="timesheet_uom_timer"/>









35. daterange

Float Type: Datetime




<field name="date_end" widget="daterange" nolabel="1" class="oe_inline" options="{'related_start_date': 'date_begin'}"/>









timesheet_uom

Filed Type: timesheet_uom




<field name="unit_amount" widget="timesheet_uom"/>









36. pad

Float Type: Char




<field name="description_pad" widget="pad" nolabel="1"/>









37. tate_selection

Field Type: Selection




<field name="kanban_state" widget="state_selection"/>









38. many2many_checkboxes

Float Type: Many2many




<field name="inbound_payment_method_ids" string="Methods" widget="many2many_checkboxes" attrs="{'invisible': [('type', 'not in', ['bank', 'cash'])]}"/>









39. video_preview

Float Type: Char




<field name="embed_code" class="mt-2" widget="video_preview"/>









40. res_partner_many2one

Field type: many2one

<field name="partner_id"  widget="res_partner_many2one"
 context="{'default_name': contact_name,'default_title': title,
       'default_street': street,'default_street2': street2,
       'default_city': city,'default_state_id': state_id,
       'default_zip': zip,'default_country_id': country_id,
        'default_function': function,'default_phone': phone,
      'default_mobile': mobile,'default_email': email_from,
      'default_user_id': user_id,'default_team_id': team_id,
      'default_website': website,'show_vat': True}" />

These are the various types of widget tools that are used during the development of the Odoo platform to bring in advanced functionalities of operation to the platform by simplifying the development and programming aspects.

In conclusion, all the 40 types of widget tools that have been described in this blog will be helpful in the operational aspects of the platform. You can read the following blog to have a clear understanding of further other widget tools which have been used and can be used in Odoo: Widgets in Odoo
